Save the isoconfig.xml and then try generating the isometric drawings using this style. Please make sure that the ComponentScheme is enabled, i.e., Enabled="true".Ĥ. See the entry in green that I added below. Add a new ComponentScheme entry for SupportTag. Open the IsoConfig.xml file in a text editor (or xml editor).ģ.
For example, for the style Check_ANSI-B in Project10, you would go to: \Project 10\Isometric\Check_ANSI-BĢ. Go to the folder associated with the Iso style that you going to use.
Although there is no UI to enable/disable tag annotations for Supports, you should be able to enable Tag annotation for Supports by modifying the isoconfig.xml.ġ.
